About small gear

Types of small gears

Gears are mechanical parts with teeth that work in a round shape, transferring motion and changing force direction. They are common components of machines and usually work together with other gears. Generally, the working principle involves the meshing of teeth. Small gears are the smaller-sized gears in a relationship with larger gears.

  • Spur gear

    The most common type of gear. It usually meshes with other spur gears. They have straight teeth that are perpendicular to the gear axis. Their simplistic design allows for easy manufacturing, thus making them some of the most common types of gears. They are mostly used in gear trains where high accuracy is needed.

  • Bevel gear

    Small bevel gears are designed to help in changing the axis of rotation. They can efficiently change the axis of rotation to 90 degrees. One notable feature about bevel gears is that they are conical in shape. Like spur gears, bevel gears can also have straight or curved teeth.

  • Crown Gear

    A type of bevel gear. Features large teeth that can mesh directly with a pinion gear. Their teeth look like those of spur gears but are set on a vertical plane. This allows them to efficiently transmit power between two shafts that are perpendicular to one another.

  • Worm gears

    Worm gears are used to provide high torque at low speeds. They usually have a screw-like design that meshes with a gear resembling a sprocket wheel. When two gears mesh, the friction between them creates a driving force that transmits motion. In most cases, a worm gear drives a worm wheel. They can change the motion direction up to 90 degrees. Additionally, they are known to provide high reduction ratios.

Specification and maintenance of small gears

Gear teeth are the main characteristic of gear specifications. The number and shape of gear teeth can refer to the used power transmission applications. Mainly, there are two tooth shapes: circular teeth and hypoid teeth.

  • Gear teeth number: Gear teeths are the teeth on the small gear that interlock with other gears. The easy way to identify gear teeth is by counting them. Generally speaking, the higher the teeth number, the greater the load capacity and the finer the speed ratio.
  • Tooth shape: Gear teeth shape will directly influence how the teeth interlock and transfer power. Circular teeth look like a circle. They interlock smoothly with other gears, transferring power efficiently. The teeth of helical gears look like a curve, which can provide a larger contact area and smoother power transmission.

In addition to gear teeth, small gear material selection also has an effect on gear performance. Metal small gears, such as brass gear and steel gear, are strong and durable. They are not easy to break and can use them in high-strength applications. Plastic small gears, such as nylon gears, are light and can resist certain chemicals and temperatures. They often use in some delicate or low-energy applications.

According to the research, the working temperature of small gears must stay between -20 °C and +80 °C. Under this temperature scope, gear performance is good, and gears will not be damaged. When the environment gears work is more than this temperature scope, it may cause the gear to break or work poorly.

Proper maintenance is crucial for ensuring the optimal functioning of small gears. Regular cleaning of the teeth is an essential maintenance activity. Users should remove debris and dirt from the gear teeth using a soft cloth or brush. Cleaning should be done gently to prevent damage to the teeth. Regular lubrication is another critical maintenance task. Applying lubrication to the gear teeth helps minimize friction and ensure smooth operation. Users should select suitable lubricants for small gear applications, including oil or grease, and apply a thin layer to the gear teeth.

Uses of small gears in industries

Small gears are important components in various machines. They make the machines work by transferring energy and motion between different parts. Here are some common uses of small gears in machines:

  • Automotive industry: Small gears help with speed control and power distribution in vehicles. They usually work in conjunction with pinions in the differential to optimize torque and traction, ensuring that the vehicle maintains a firm grip on the road despite changing conditions.
  • Medical devices: Small plastic gears are often found in precise medical devices like pumps and inhalers. They allow for precise movement and control.
  • Robotics: Mini gears and micro gear motors have a significant role in robotics. They are used to control movement and provide robots with the ability to perform different tasks.
  • Consumer electronics: Small gears are key parts of common electronic devices such as smartphones, cameras, and drones. They enable these devices to work accurately and smoothly.
  • Optical instruments: Optical equipment, such as microscopes and telescopes, relies heavily on small gear sets. In these instruments, fine reduction gears are used to enable precise focusing and adjustment of optical pathways.
  • Aerospace applications: Aerospace technology often makes use of small gear shafts. These components are critical in the transmission and distribution of power within aircraft engines and other high-precision machinery used in space exploration.
  • Office machinery: Modern workplaces rely on small gear wheels to facilitate the operation of copiers, printers, and shredders, among other equipment. These tiny gears play an essential role in ensuring accurate and efficient document reproduction, printing, and destruction processes.

These are just a few examples of how small gears are applied in different areas. Their presence is still felt in many machines made manually or using industrial-scale manufacturing methods.

How to choose small gears

Selecting the right small gear set involves evaluating several factors that affect how well the gear will perform its job.

  • Machinery requirements

    Consider the working machine and its purpose. Think about the load capacity, torque, speed capacity, direction, and the way it is supposed to function. Check if the gear will work well with the other parts of the working machine. A successful small pinion gear selection involves getting a gear that will work well with the other existing parts in a machine.

  • Environment

    The setting where the gear works must be considered. Think about the temperature, humidity, and possible exposure to dirt or chemicals. Also, think about how often it will be used daily or weekly. In a harsh environment, choose materials and coatings that can resist corrosion or contaminants.

  • Cost

    When choosing small gears for an application, the budget and cost must be considered. However, even if the cost is low, it is important to ensure that the gear will meet the job demands and maintain its long-term use.

  • Future needs

    Thinking about future needs can help with the gear selection process. Consider how the working machine may change in the next few years. To support possible upgrades or changes later, get a gear that can manage higher loads or speeds than what is needed now.

Small gear FAQ

Q1: Do small gears break?

A1: If the force acting on the gear exceeds its breaking strength, it will break. Also, factors like wear, fatigue, and heavy load can cause small gears to break.

Q2: Are small gears durable?

A2: Small gears can be durable depending on the material, maintenance, proper lubrication, and operating conditions.

Q3: Can small gears withstand heat?

A3: Excessive heat can cause small gears to expand, increasing the risk of breaking. However, small gears that are heat treated to improve hardness can withstand heat.

Q4: Do small gears control torque?

A4: Yes. Small gears control torque. When a small gear is driven by a large driving gear, it will increase the rotational output. In such a situation, the small gear will amplify the torque of the system.
