Embedded x86 boards come in various types. These include:
Single Board Computers (SBCs)
Embedded x86 Single-Board Computers (SBCs) integrating all essential components into a compact board are available. They offer powerful processing capabilities and versatility in applications ranging from industrial automation to digital signage. While their processing power may differ, most x86 boards maintain a fixed form factor designed to host specific hardware components. This becomes important in embedded system designs where stability is essential.
Box PCs and Panel PCs
Box PCs are rugged solutions with embedded x86 boards designed to operate under harsh conditions. Also, Panel PCs incorporate touchscreens for interactive applications, making them suitable for industries like manufacturing. Their designs are optimized for compactness and durability, ensuring reliable performance in tight spaces.
COM Express Modules
COM Express boards are compact, standardized computer-on-module (COM) boards for various applications. They are suitable for systems requiring easy upgrading, like industrial control systems. In addition, these boards maintain powerful processing capabilities, hence supporting the latest software and communication interfaces.
Qseven Modules
Manufacturers designed Qseven modules to be more mobile and smaller than COM Express, focusing on slim and lightweight designs. They are in systems where space is at a premium but still require x86 processing power. These boards are used in portable medical devices and mobile computing systems to ensure smooth operation.
ATX and MicroATX Embedded Motherboards
For long-term stability, some embedded systems use ATX and MicroATX motherboards based on x86 architecture. Such boards are often housed in enclosures for industrial PCs. In addition, their extended connectivity options and performance capabilities make them suitable for complex applications requiring multiple expansion slots.
Embedded x86 boards come with various materials and durability.
Military-grade Components
Manufacturers make some embedded x86 boards for defense and aerospace applications using MIL-SPEC components. These components have resistance capabilities to extreme temperatures, vibrations, and electromagnetic interference (EMI). They also have a long mean time between failures (MTBF), ensuring reliable performance in critical missions.
Sturdy Support for Long-Term Operations
In industrial settings, boards come with capacitors and connectors that support continuous working under high temperatures. These components are rated for longer life in environments where temperature fluctuations and dust are common. Also, the solder joints for these boards are reinforced to reduce the risk of cracking if the temperature changes or if they are exposed to heavy vibrations.
Heat-resistant and Waterproof Designs
Many embedded x86 boards have heat sinks, fanless designs, and conformal coating.
Examples of conformal coating include epoxy and acrylic. These coatings protect the PCBs from moisture, dust, and chemicals, making them ideal for outdoor and industrial applications. In addition, heat sinks and fanless designs allow for passive cooling. This feature helps maintain temperature stability over long periods, even in high-heat environments.
Ruggedized Connectors and Fastening Systems
Embedded x86 boards often come with reinforced connectors and soldered components to handle heavy vibrations and shocks. Their connectors are designed with locking mechanisms to ensure stable connections even in fluctuating environments. Manufacturers also strengthen the mounting points for the boards in enclosures or systems to prevent their bending or breaking under heavy loads.
Industrial use materials
A manufacturer builds embedded x86 boards using materials such as FR-4, a type of glass epoxy laminate used on PCBs for industrial settings. They may also use low-profile aluminum electrolytic capacitors.
This capacitor type is often seen in devices that require compact size but still manages to offer durability. Furthermore, while many consumer devices use standard capacitors, military, industrial, and commercial boards use high-endurance capacitors for reliability.
Embedded x86 boards offer significant commercial value in many industries.
Cost-effective Complex Computing Solutions
Embedded x86 boards provide the benefits of a standard PC in embedded applications. These applications use board options that may not require the performance capacities of general computing systems. For instance, point of sale systems and medical devices. In such places, the operational costs saved over time will be significant reaching into the thousands. This is especially true for large-scale deployments
Versatility Across Industries
Manufacturers use embedded x86 boards in various industries, including industrial automation, telecommunications, and IoT. These boards support multiple operating systems, such as Windows and Linux. This makes them suitable for diverse applications. Telecommunications companies use them in network routers and edge devices for faster data processing capabilities.
High Performance for Data-intensive Applications
Embedded x86 boards offer a good performance-per-watt ratio. This is more so when compared to alternative architectures like ARM, especially for data-intensive applications. They are ideal for video processing systems, advanced robotics, and embedded medical imaging devices due to their powerful processing capabilities.
Supports Legacy Software and Hardware
The x86 architecture's commercial value of embedded x86 boards is that they can run legacy applications. This embedded x86 boards makes it easier for industries to modernize their systems without entirely overhauling existing software. The architecture's consistency also ensures long-term viability and support for a wide range of peripherals and expansion options.
Remote Monitoring and Control Systems
Embedded x86 boards are found in many systems requiring remote management and monitoring. This includes building automation and smart grid systems. These boards help businesses efficiently manage their assets in real time, leading to improved operational efficiency, reduced downtime, and significant cost savings.
Business owners can use the following points when shopping for embedded x86 boards.
Operational Temperature Range
Depending on the environmental conditions where the board will be used, buyers need to look for a suitable manufacturer-rated temperature range. For industrial or outdoor applications, select a board that can operate effectively within wide temperature ranges.
Compliance and Certification Requirements
Buyers should consider the relevant industry certifications and regulatory compliance standards the board needs to meet. Such standards include ISO or IPC for industrial applications, MIL-STD for aerospace or defense, and CE for European safety compliance.
Expansion Capabilities
Embedded x86 boards often need to accommodate additional components such as storage drives, network cards, or custom I/O interfaces. These boards frequently come with extra slots and ports to support future hardware upgrades. Buyers should get boards with sufficient expansion slots, GPIO header configurations, and connectors for PCIe, SATA, and USB.
Power Consumption and Efficiency Rating
Power consumption is a key factor for embedded systems, especially those that operate in remote locations. Boards with lower TDPs help to minimize energy costs and often require less complex cooling systems. A few manufacturers also incorporate power-saving features like dynamic frequency scaling and sleep modes.
IO Interface Versatility
Embedded systems often need to communicate with many sensors, actuators, and other devices. Choose boards that come with various I/O interface options, such as UART, I2C, SPI, and GPIO.
Industry-specific features
Embedded boards have use cases in distinct industries. For example, embedded x86 boards for telecommunications may include support for 5G networking and advanced power management. Medical equipment manufacturers will look for boards with low-power design and board-level power sequencing.
An embedded x86 board is a type of small form factor electronic circuit board designed to perform dedicated functions within larger systems. These boards utilize the x86 instruction set architecture (ISA), commonly found in personal computers. They provide powerful processing capabilities for a wide range of embedded applications.
Because of their versatility, x86 boards are used in many applications. For example, they are embedded into industrial machines for automation and control, network devices for telecommunications, digital signage systems, point-of-sale terminals, and medical devices. In all these applications, the boards act as the processing and control unit.
Yes, embedded x86 boards support multi-core processors and advanced power-saving features. This makes them efficient for data-intensive tasks like high-definition video processing, complex simulations, and real-time data analysis. They also run complex operating systems like Windows and Linux.
Manufacturers mostly use embedded x86 boards in industrial automation and IoT, telecommunications, digital signage, and medical devices. Consumer electronics and commercial computing also use them. For example, point-of-sale terminals and network routers utilize these boards for their reliability and performance capabilities.
Embedded x86 boards have an average lifespan of around five to ten years. However, it all depends on the environmental conditions they will be exposed to and the specific use case. For example, boards operating in harsh industrial environments will age faster than those used in controlled environments.
