Attributes
Bottom mount 4-bolt flangeMounting Type
2025-09Manufacturing Date Code
HYXL-HH26Model Number
Inertial navigation sensor FOG-INS IMUType
Attitude heading position for air and landUsage
Roll ±180° Pitch ±89.5° Heading 0/360°Sensing Range
Description:FOG INS with GNSS aiding high-accuracy AHRS
Place of Origin:Shaanxi, China
Series:HH series
Features:Fast align ≤3 min high stability RS-422 wide temp
Theory:Fiber optic gyro INS
Output:Attitude heading position velocity via RS-422
Description:BIST transfer and ground self alignment
Interface:RS-422
Power - Rated:≤12 W steady ≤24 W transient
Voltage - Supply:18 36 V DC
Axis:3-axis gyros 3-axis accels 3-axis attitude
Terminals:Connectorized RS-422 service port
Transfer Alignment Time:≤3 min
Ground Self-Alignment Time:≤5 min
Integrated Heading Accuracy:≤0.05°
Integrated Attitude Accuracy:≤0.02°
Pure Inertial Heading Accuracy:≤0.2°
Pure Inertial Attitude Accuracy:≤0.1°
Measurement Range - Roll:-180°~+180°
Measurement Range - Pitch:-89.5°~+89.5°
Heading Angle:0°~360°
Operating Temperature:-40°C~+60°C
Selling Units:Single item
