תכונות
Shaft screw mountMounting Type
2025Manufacturing Date Code
HYXL-BMQ01Model Number
Servo platforms,stabilization/aiming systems,EO/IRUsage
Rotary shaft (stator + rotor)Actuator Type
18bit absolute inductive encoder,0-360 °,±0.02 °Description
Type:Absolute inductive encoder (non-contact)
Place of Origin:Shaanxi, China
Features:18-bit resolution;≤ 0.02 ° accuracy;non-contact
Theory:Inductive (non-contact)
Output:SSI (RS-422 differential),24-bit frame,18-bit data
Built in Switch:None
Voltage - Supply:5 V DC ± 5 %
Termination Style:500 mm flying leads (AFR-250-0.1 mm² cable)
Orientation:Coaxial rotor/stator; full 360 ° rotation
Communication Interface:SSI (RS-422 differential)
Rotational Life (cycles Min):> 1 x 100000000 cycles (theoretical unlimited)
Dimensions (L x W x H):22.4 x 22.4 x 8.0 mm
Weight:≤ 15 g (incl. housing)
Bias Stability:≤ 1 °/h
Zero Bias over Temperature:±0.005 °/s (-40 °C - +70 °C)
Angular Random Walk (ARW):0.15 °/h
Scale-Factor Nonlinearity:≤ 100 ppm
Data Output / Update Rate:Up to 2 kHz
Latency (Data Delay):≤ 1.5 ms (including comms)
Shock Resistance:100 g, 11 ms half-sine
Vibration Resistance:20 g, 10-2000 Hz
מכירת יחידות:Item tunggal
