Attributes
Galvanized Steel Wire Roperope material
Triangular Strand Rope, Linear Contact Rope, Multi-layer Rope, Multi-strand Rope, Non-round Strand Rope, Steel Wire RopeRope Type
37MMwire rope diameter
Henan, ChinaPlace of Origin
Standard: 10-15 m, Extendable:CustomizableController Cord Length
Carbon Structural Steel, Galvanized Steel Wire, Stainless Steel Wire, Special Alloy Steel WireMaterial
Power Source:Electric Motor Drive
Strap length:Not Applicable
Winch Mounting Location:Underground Anchored to reinforced concrete founda, Surface Mounted on steel support platform
Model Number:2JK-3.0*1.8P
Brand Name:wanfeng
Application:Coal mines, Metal mines, Non-metallic mines, Vertical shafts, Inclined shafts, Tunnel construction, Material hoisting, Personnel transport, Coal mine vertical shaft: Material/Personnel hoist, Metal mine inclined shaft: Ore transport, Tunnel construction: Equipment lifting
Customized support:OEM, ODM
End Type:Normal fixed-point stop, Emergency two-stage braking, Full braking stop
Power:500KW
Product Type:Electric Wire Rope Hoist Winch, Electric Mine Shaft Hoist Winch, Electric lift winches elevators, Mining machinery devices
rope length:1st layer 414M, 2nd layer 844M, 3rd layer 1282M
Standard:CE, KA, MA, ISO 9001 Certification
Strap width:Not Applicable
Voltage:Rated Voltage 380V/660V/1140V, Voltage Tolerance ±10%
Warranty:1 Year
Winch Bar Design:Standard, Combination, Ergonomic
Drum Diameter:3000MM
Drum Width:1800MM
Center distance between two drums:1890MM
Maximum Static Rope Tension:13 Ton
Maximum Static Tension Difference:8 Ton
Lifting Speed:4.1M/S
Lifting Height or Transport Length:1st layer 414M 2nd layer 844M 3rd layer 1282M
Rated Motor Power (Max.):500KW
Motor Speed:≤750 r/min
Selling Units:Single item
Single package size:1460X1100X350 cm
Single gross weight:36500.000 kg
