Attributes
rail mountingMounting Type
2025Manufacturing Date Code
PSD-DG1Model Number
PUSHTONBrand Name
Convert the load cell 2 millivolt voltage signal tUsage
1/10000Accuracy
Description:Convert the millivolt signal of the load cell into
Type:Load Cell
Place of Origin:Henan, China
Series:PSD-DG
Features:Force Weighing Signal Transmitters
Theory:Digital signal amplifiers
Output:0-10V/4-20mA/RS485
Description:Weigh rail module
Actuator Type:5VDC ± 2%,100mA
Voltage - Supply:DC12V/24V
Recommended Operating:DC12V/24V
Max Power Consumption:3W
Digital Communication Interface:RS485/RS232/Optional CANBUS
Weight Display Range:-9,999~+99,999
Scale Capacity:Setting Range 1~99,999
Scale Division:Optional 1, 2, 5, 10, 20, 50, 100, 200, 500
Display Resolution:1/50,000
Decimal Point Position:Optional 0, 0.0, 0.00, 0.000, 0.0000
Display Refreshing Time:Setting Range 0.01~ 1.00s
Selling Units:Single item
Single package size:12X7.5X7.5 cm
Single gross weight:0.300 kg
