Atribut
CNC Routermachine type
CNCcnc or not
Shandong, Chinaplace of origin
220V/380Vvoltage
1800weight (kg)
1 Yearwarranty
range of spindle speed(r.p.m):6000 - 24000 rpm
positioning accuracy (mm):0.03
number of axes:3
No. of Spindles:Single
travel (x axis)(mm):2000
travel (y axis)(mm):3000
repeatability (x/y/z) (mm):0.03
Spindle Motor Power (kw):2.2
brand name:MVIP
dimension(l*w*h):2100*3100*500
key selling points:Easy To Operate
machinery test report:Provided
video outgoing-inspection:Provided
core components:Bearing, Motor, Pump, Gear, PLC, Engine, Gearbox
Machine Frame:Steel Tube Casting
Working Table:Aluminum T-Slot PVC Table
Working area:2000x3000x200mm
Application:Woodworking Processing
Control system:DSP Handle or Customization
X Y Axis Transmission:Taiwan TBI Helical rack and pinion
Z Axis Transmission:Rolling ball screw
Motor and Driver:Stepper Motor and Leadshine Driver
Inverter:Best or Fuling Inverter
Color:Customization
jual Unit:item tunggal
ukuran paket tunggal:2200X3200X500 cm
tunggal berat kotor:1000.000 kg
