About pvc smooth pipe extrusion line

Types of PVC Smooth Pipe Extrusion Lines

Through the PVC smooth pipe extrusion line, businesses can produce different types of smooth PVC pipes to meet market demand. The following table outlines some commonly discernable characteristics of smooth PVC pipes.

  • Material

    Rigid PVC material is widely used in the construction and water supply industries because of its high impact resistance and long service life. Flexible PVC material finds application in electrical conduit pipes, offering protection for electrical cables while enabling ease of installation and flexibility.

  • Manufacturing Process

    Injection-molded PVC pipes are primarily used in the furniture industry, such as manufacturing chairs and tables, as well as the plumbing industry. The extrusion process is suitable for producing long and continuous smooth PVC pipes for water supply, drainage, and electrical conduit systems.

  • Size

    Smooth Large-diameter PVC pipes are commonly used in agricultural applications, such as irrigation systems and industrial large-diameter smooth PVC pipes, which are suitable for conveying large volumes of fluids in industrial processes. Long smooth PVC pipes are typically used in construction, water supply, and drainage industries. Bulk purchasers can check the product description for details on the specific length and diameter.

  • Joint Method

    Socket and Solvent Joint Pipes: These types of joints are commonly used in the plumbing industry, where smooth PVC pipes need to be tightly connected to ensure no water leakage. Threaded Pipes: They are commonly used in the machinery industry, where smooth PVC pipes require disassembly and assembly.

Specification and Maintenance

  • Output Capacity:

    The output capacity of a PVC pipe extrusion line is usually expressed in kg/h. PVC smooth pipe extrusion lines can produce different types of pipes at rates ranging from 50 to 500 kg/h.

  • Extruder Size:

    The diameter of the screws of the PVC smooth pipe extrusion machines varies according to the material and the type of the machine. The screw diameters typically range from 60 to 150 mm.

  • Power:

    The motor power of the PVC pipe extrusion machines is indicated in kilowatts (kW). Different types of machines for PVC pipes have motor power ranging from 18.5 kW to 75 kW.

  • Length-Diameter Ratio:

    The length-to-diameter ratio of the screws used in PVC smooth pipe extrusion lines also varies according to the material and the specifications of the machine. Generally, the length-to-diameter ratio is between 18:1 to 30:1.

  • Die Sizes:

    The die sizes of a PVC pipe extrusion line are the diameters that can be used to mold pipes of different dimensions. The die sizes usually range from 10 mm to 800 mm.

Maintenance

For a PVC pipe extrusion line to operate optimally for a long time, it is important to regularly inspect and maintain the machine parts.

  • Daily Maintenance:

    This typically involves machine cleaning. The PVC pipe extrusion machine should be cleaned thoroughly after production to prevent any material residue buildup that can affect future product quality.

    Daily lubrication of moving parts of the machine is also necessary. Doing this helps to prevent wear and tear and reduces the operating noise of the equipment.

  • Weekly Maintenance:

    Weekly maintenance requires operators to inspect critical parts of the extrusion line, including the heater, vacuum calibration tank, and extrusion die. They should look out for signs of damage or material blockage.

    Manufacturers recommend that operators calibrate the pipe extrusion die regularly to ensure that the pipeline produced is of the correct specification.

  • Monthly Maintenance:

    A thorough cleaning of the entire extrusion line is required once a month. This helps to ensure that there are not any residual materials in the machine that can affect product quality and the smooth operation of the equipment.

    Catastrophic failure of the extrusion machine can be avoided by conducting preventive maintenance on the machine once every month. During this routine check, the operator should inspect the main motor's gear box, driving belt, and clutch. Any loose or worn-out parts should be adjusted or replaced immediately.

Uses of PVC Smooth Pipe Extrusion Lines

PVC Smooth Pipe Extrusion Lines can produce various types of PVC smooth pipes used in different industries.

  • Construction:

    PVC smooth pipes manufactured by these extrusion lines are commonly used in construction as plural pipes, which serve as electrical conduits. They protect and route electrical wires within walls and ceilings. Additionally, PVC smooth pipes can be used as plumbing pipes for both water supply and drainage systems.

  • Automotive and Transportation:

    PVC smooth pipes are lightweight and durable tubes often used in vehicle assembly and design. They can serve various applications, such as protecting electrical wiring or acting as hollow inserts that reduce the weight of the vehicles.

    PVC smooth pipes can be fabricated into cable management systems, including trunking and conduits. In this application, they organize and protect electrical cables.

  • Medical:

    On some occasions, PVC smooth pipes can be used as medical devices or components, such as catheters, IV tubes, and neonatal products. The transparent PVC pipes allow physicians to see the flow inside the tubes and make them easier to use with other medical devices.

  • Agriculture:

    The irrigation system extensively uses smooth PVC pipes. They can also be used in agricultural drainage and tubing for livestock watering systems.

  • Furniture and Sporting Goods:

    PVC smooth pipes can be manufactured to produce various kinds of furniture, including indoor and outdoor furniture, as well as sporting equipment, such as bows for tents, water guns, and other sporting instruments.

  • Industrial:

    PVC smooth pipes are also used in various industrial applications. They may be employed as lightweight, corrosion-resistant conduits for electrical wiring in industrial settings or as protective sleeves for cables and hoses in manufacturing equipment.

The versatility and adaptability of smooth PVC pipes make them an economical and practical choice for designers and engineers in different fields. The proper selection of materials and extrusion technology will ensure the quality of the smooth PVC pipes and meet the demand for use in specific industries.

How to choose a PVC smooth pipe extrusion line

When choosing a PVC smooth pipe extrusion line, it is essential to consider the following factors:

  • Production capacity

    The buyer should determine the amount of output they desire and choose a machine that can meet those needs. If the buyer needs to produce a large number of pipes, they should go for a high-capacity extrusion line. On the other hand, a small to a medium capacity line would be sufficient for low demand.

  • Flexibility and automation

    When purchasing a pipe extrusion line, it is crucial to consider automation and flexibility features like touchscreen controls, ease of operation, and automated feeder systems. These aspects can influence how well the machine meets production requirements and its ability to adapt to different types of pipes and materials.

  • Quality and Supplier

    To ensure good performance and a long-lasting machine, it is important to pick an extrusion line that is made well. It is also essential to choose a reliable supplier who provides good customer service and support. Considering these factors will help in selecting a durable and efficient machine that meets the buyer's needs.

  • Energy efficiency and cost

    When choosing a machine, it is essential to consider its energy efficiency in terms of power requirements. This is important for minimizing production costs in the long run.

  • Technical support and spare parts availability

    Buyers should look into the supplier's technical support and the availability of spare parts. This will ensure that the machine can be serviced easily and any required replacement parts can be obtained without delay.

Q&A

Q1: What is the difference between rigid and flexible PVC pipes?

A1: Rigid PVC pipes are often used for drainage, waste, vent, and pressure pipe systems. Flexible PVC pipes are used for applications like swimming pool plumbing and cable protection.

Q2: What is the difference between PVC and uPVC pipes?

A2: Both involve the same material, but uPVC smooth pipes use less chlorine in the production process, which makes them harder and more ideal for structural applications.

Q3: What Extrusion method is used for PVC pipes?

A3: In the case of PVC smooth pipes, rigid PVC resin is directly injected into an extruder, where it is heated, melted, and formed into the desired shape.
