Lancer speed sensor

Types of Lancer Speed Sensor

A Lancer speed sensor detects wheel rotation and helps the vehicle's computer determine how fast it's moving. There are different types of Lancer speed sensors, and they include:

• Gear tooth:

  The gear tooth speed sensor uses a magnetic coil and a toothed gear wheel to measure speed. It generates an electrical signal when the gear passes by the sensor, with the magnetic field changing. The number of teeth on the gear determines the sensor's output signal shape.

• Hall effect:

  The Hall effect sensor utilizes the Hall effect phenomenon in semiconductors to measure speed. It produces a digital pulse train signal proportional to the gear's rotation speed past the sensor. More pulses per revolution or fewer teeth on the gear result in a lower output signal frequency.

• Inductive:

  Inductive speed sensors rely on electromagnetic induction to measure changes in magnetic fields caused by rotating elements. They convert mechanical motion into electrical signals, with varying induced currents representing different speeds or directions of movement.

• Resistive:

  Resistive speed sensors change resistance in response to mechanical motion. The varying resistance alters an electrical signal sent to other systems, indicating changes in speed or position. These sensors are simple yet effective for basic speed detection tasks.

• Capacitive:

  Capacitive speed sensors measure changes in capacitance related to the proximity or movement of adjacent objects. As elements move closer or farther apart, the varying capacitance alters the electrical signal, allowing detection and measurement of relative speed or position changes.

• Magnetoresistive:

  Magnetoresistive sensors utilize materials whose electrical resistance changes in magnetic fields. They detect speed by measuring the varying resistance resulting from the proximity of magnetic elements, enabling precise motion tracking in various applications.

• Optical:

  Optical speed sensors use light (infrared, laser, or visible) to detect changes in reflected or transmitted light patterns. These changes are processed to determine speed or position, leveraging the principles of optics and light interaction with moving elements.

Specification and Maintenance of Lancer Speed Sensors

Specification

Speed sensors have different specifications depending on the vehicle's make and model and the sensor's type. Here are some common specifications:

• Voltage:

  The sensors generate a voltage signal that varies depending on the speed of the rotation. The voltage output is typically 1-2V peak to peak, with an impedance of 1000 ohms.

• Frequency:

  The frequency of the output signal is proportional to the speed of the rotation. At low speeds, the frequency is 10-20 Hz, and at high speeds, it can exceed 1000 Hz.

• Temperature Range:

  The temperature range indicates the sensor's ability to operate in extreme conditions. The temperature range is typically -40 to 125 degrees Celsius.

• Material:

  The materials used to manufacture speed sensors must be resistant to mechanical stress and temperature. Common materials include steel, ceramics, and polymers.

Maintenance

Lancer speed sensor maintenance is crucial to ensure its reliable operation and increase its service life. Here are some common maintenance requirements:

• Regular Inspection:

  It is essential to check the condition of the speed sensor and its connectors regularly. Pay attention to damage, wear, corrosion, and other mechanical or electrical defects. Carry out visual inspections at least once a month.

• Cleaning:

  Contaminants such as dust, moisture, oil, and dirt can affect the performance of speed sensors. Clean the sensor and its connectors carefully using appropriate cleaning products and methods. Use a dry cloth to wipe the sensor surface. Compressed air can also blow away any particles or contaminants that may be present.

• Wiring Inspection:

  Check the wiring harness for signs of damage, such as fraying, cracks, or breaks. If any issues are noticed, replace the wiring harness immediately. Ensure all electrical connections are tight and secure.

• Signal Checking:

  Use an oscilloscope or a multimeter to check the output signal of the speed sensor. Compare the obtained readings with the specifications of the sensor. If the signal is unstable or outside the normal range, it may be necessary to replace the sensor.

• Temperature Monitoring:

  Speed sensors can be damaged by high temperatures. Monitor the temperature of the sensor and its surroundings. If the temperature exceeds the specified limits, take measures to cool the sensor and improve the airflow.

• Software Updates:

  In some cases, speed sensors are used in conjunction with control units that require software updates. Follow the manufacturer's recommendations and install the latest software version if necessary.

• Replacement:

  Even with timely maintenance and care, speed sensors can wear out or become faulty over time. If problems with the sensor are detected, replace it as soon as possible to avoid issues with vehicle speed control and stability.

How to choose Lancer speed sensors

Before sourcing Lancer speed sensors, it's important to understand the factors that affect their selection.

• Vehicle Compatibility

  When selecting a speed sensor for a vehicle, it is important to consider the make, model, and year of the vehicle. This is because different vehicles use different types of sensors and are designed to fit in specific locations. The speed sensor must be compatible with the vehicle's engine control unit (ECU) to ensure proper functionality. Incompatibility can result in error codes, sensor failure, and even damage to the vehicle's transmission.

• Quality and Reliability

  It is advisable to choose a quality speed sensor from a reliable manufacturer or supplier. This is because quality sensors last longer and provide accurate speed readings. On the other hand, faulty sensors can cause erratic readings, which can damage the transmission system. Reliable sensors support the smooth operation of the vehicle and reduce the need for frequent replacements.

• Check the Warranty

  Before purchasing a speed sensor, it is important to check the warranty offered by the manufacturer or supplier. A good warranty is an indicator of the quality and durability of the sensor. Additionally, it protects the buyer from defects and failures.

• Installation

  Different speed sensors have different installation requirements. Some have simple plug-and-play installation, while others may require wiring connections and mounting. When choosing a speed sensor, it is important to consider the ease of installation. This is because complicated installation may require professional help, resulting in extra costs.

• Price

  Price is an important factor to consider when choosing a Lancer speed sensor. High-quality speed sensors are generally more expensive than their low-quality counterparts. However, this does not mean that all high-priced sensors are quality or all low-priced sensors are of low quality. It is advisable to compare the prices from different suppliers and also consider the quality of the sensor.

How to DIY and Replace Lancer Speed Sensor

The vehicle's speed sensor is very important for its proper functioning. The good news is that the speed sensor replacement is not as complicated as most people think. It is very possible to replace the speed sensor without professional help. However, it is advisable that before any attempt to replace the sensor, the first user should be well informed and educated about the matter. It is very necessary to consult a professional mechanic when in doubt. Below is a simple guide on how to replace the speed sensor.

Before the replacement, ensure to have the right tools that will make the work easier. This includes a jack and jack stands, ratchet and socket set, wrench set, torx screwdriver, new speed sensor, and electrical connector cleaner.

• 1. First and foremost, ensure that the vehicle is parked in a safe and level environment. Then, turn off the ignition and put on the warning lights.
• 2. For safety measures, disconnect the battery before starting the work.
• 3. Lift the vehicle using the jack and ensure it is well secured with jack stands.
• 4. Locate the old speed sensor. This is done by referring to the service manual to know its exact location in the engine.
• 5. Use a ratchet and socket to remove the bolt holding the sensor in place and gently twist the sensor loose with a torx screwdriver.
• 6. After removing the old sensor, clean the mounting area to ensure it is clean before installing the new sensor.
• 7. Then, install the new sensor in the mounting area and ensure it is well tightened.
• 8. After the sensor installation is completed, reconnect the vehicle's battery and start the engine to ensure that the sensor is well working.

Q&A

Q1: How can I know if my speed sensor is faulty?

A1: As mentioned earlier, the speed sensor is linked to various components of the vehicle. Lancer's P0560 speed sensor code indicates that the vehicle control module (VCM) or engine control module (ECM) is not receiving the correct speed data. If the ECM gets incorrect data about the vehicle's speed, it may not be able to control the transmission properly. As such, the check engine light will be on, and there will be signs of transmission problems. The transmission problems are a clear indication that the speed sensor is faulty.

Q2: Can I drive with a faulty speed sensor?

A2: Yes, but it's not recommended. A faulty speed sensor can cause various problems, such as inaccurate speed readings, poor fuel efficiency, and transmission shifting issues. While one can drive with these problems, they can worsen over time and potentially lead to more severe engine or transmission damage. Addressing speed sensor issues promptly is advisable to avoid further complications and maintain vehicle performance and safety.

Q3: How long does it take to replace a speed sensor?

A3: The time it takes to replace a speed sensor depends on the make and model of the vehicle and the sensor's location. Generally, speed sensors are located near the transmission or wheels and are accessible. Replacing a speed sensor can take anywhere from 30 minutes to a few hours. An hour is a reasonable time to have the lancer speed sensor replacement exercise.

Q4: Can I replace a speed sensor myself?

A4: Yes, but having some mechanical knowledge is important. The speed sensor replacement process is simple. First, the old sensor is removed, and the new one is installed in its place. The vehicle control module (VCM) or engine control module (ECM) is then reset to recognize the new sensor. It is advisable to consult the vehicle's service manual for specific instructions and ensure proper installation.

Q5: What is the warranty period for a new speed sensor?

A5: The warranty period for a new speed sensor varies depending on the manufacturer and supplier. Generally, it ranges from 12 to 24 months. Some suppliers on Alibaba.com offer a warranty period of up to 36 months. Buyers should check the supplier's warranty conditions and ensure they are satisfied.
