Capacitive oil tank level sensor

Types of Sensors for Capacitive Oil Tank Level Sensor

Capacitive sensors differ when measuring oil tank levels. They include:

• Single-point capacitive sensors

  A single-point sensor is used to detect the level of a particular substance via capacitance change. These sensors use two main electrical conductors, known as plates or electrodes. The distance between the plates of the sensors is affected by the level of the substance. The capacitance will vary if the substance is a liquid, solid, or another material that connects one of the plates to the ground.

• Continuous capacitive sensors

  Continuous sensors provide data regarding the level of oil in a tank without interruption. Many continuous-capacitive sensors use a dielectric filter that generates an electric field between two electrode plates. This electric field is then sent and used to measure the level of fluid in the tank. The ability of the oil to store electric energy will vary based on the fluid's level in the tank and affect the electric field.

• Multipoint capacitive sensors

  Multipoint capacitive sensors identify numerous levels, generally with three or four measurements. In such sensors, oil's dielectric dependence varies depending on the tank's level and average oil temperature. An oil tank level indicator can work effectively for those with multiple dielectrics.

Industrial Applications of Capacitive Oil Tank Level Sensor

Purchasing oil tank level sensors in bulk is beneficial for business oil companies. Below are industrial applications:

• Oil and gas industry

  Capacitive sensors are widely used in the oil and gas industry. They measure levels in storage tanks, pipelines, and separators. These tanks often contain viscous or variable-density fluids that challenge other types of level measurement. Capacitive sensors provide reliable, maintenance-free operation even in the harshest environments.

• Chemical manufacturing

  Here, these sensors help monitor raw materials and finished products. Often, these chemicals can be unpredictable. Capacitive sensors help measure levels of both liquid and solid chemicals. Furthermore, chemical plants experience many dynamic changes due to temperature, pressure, and viscosity. With this in mind, choosing reliable sensors is crucial for their operation.

• Agriculture

  In agriculture, capacitive sensors assist in monitoring fuel and lubrication oil levels in equipment storage tanks. These tanks often contain oils that can be challenging to measure using other technologies. For instance, capacitive sensors easily handle the viscous nature of some oils and fuels.

• Water and waste treatment

  Here, capacitive sensors are used to measure levels in tanks, clarifiers, and other equipment. Besides, the fluids in these systems can be highly variable in density, making other level technologies unreliable. Capacitive sensors provide consistent, accurate measurements that ensure processes run smoothly. More importantly, they prevent overflow and maintain optimum fluid levels.

Function, Feature & Design of Capacitive Oil Tank Level Sensor

Function

A deep sensing oil tank level sensor measures fluid or oil levels in tanks and containers. It does this by measuring the change in capacitance caused by the fluid's electric permittivity. The sensor consists of a pair of conductive plates or electrodes, which form a capacitor. When the fluid level rises or lowers, the capacitance changes, affecting the fluid's dielectric constant. The sensor then sends an electronic signal that transforms the capacitance into an oil level measurement.

Features

These sensors come with features such as:

• Accuracy. Capacitive sensors are accurate, making them ideal for applications where fluid level precision is vital.
• Reliable operation These sensors can easily and effectively measure fluid levels, even in harsh industrial conditions.
• No calibration The sensors are often factory-calibrated, providing users with simple plug-and-play operation.
• Low maintenance Once installed, they require little to no maintenance, which reduces operating costs and downtime.

Design

The design of capacitive oil tank level sensors is crucial to their performance. Their main components include:

• Electrodes

  These are conductive plates that form a capacitor with the fluid being measured. They are typically made from stainless steel, titanium, or other corrosion-resistant materials.

• Dielectric materials

  These are materials that allow the fluid's electric charge to pass through while preventing direct flow of electric current. Every fluid has its own dielectric constant. Dielectric constant is a metric that indicates how well a material can store electric energy. It also varies between different fluids.

• Transmitter

  This converts the capacitance measurement into an electronic signal. This signal can either be an analog output (like 4-20 mA) or a digital format (like Modbus or HART). This allows the fluid levels to be measured remotely. It also enables easy integration with other process control systems.

How to Choose the Capacitive Oil Tank Level Sensor

Here are some tips for selecting the capacitive oil sensors:

• Fluid type

  Capacitive sensors work well with various fluids, including those with different viscosities and electric charge-ability. Buyers should consider the oil's fluid type and consult the sensor manufacturer for compatibility information. This is because incompatible sensor fluids can cause inaccurate readings or even damage the sensor.

• Tank material

  Some sensors have specific installations and work better with certain tank materials. For example, metal tanks often have capacitive sensors with higher durability and more accurate oil level readings. Smooth surface liquids offer an easier time measuring than those with a rough texture. Rough surface tanks can also be coated with materials with smoother surfaces that facilitate easy capacitance measurement. These coatings can drastically improve measurement accuracy.

• Configuration of the sensor

  This is important, as they need to be installed either vertically or horizontally in the tank. A horizontal sensor will come with a longer sensing length. This enables it to measure oil levels in larger tanks more effectively. On the other hand, a vertical sensor will be better in small tanks. In such tanks, there isn't much space for horizontal installations.

• Oil tank size

  A large oil storage tank requires a capacitor sensor with a long measuring range. Hence, ensure this consideration is paramount. The level sensors in small tanks, on the other hand, will measure a short range. But even a small sensor measuring a short range in a small tank can still be accurate.

Q&A

Q1. How can customers ensure the accuracy of capacitive oil level sensors over time?

To ensure long-term accuracy, regularly check the sensors for signs of wear, damage, or contamination. In addition, recalibrating the sensors as recommended by the manufacturer will also help.

Q2. Are capacitive sensors suitable for measuring both liquid and solid oils?

Yes, capacitive sensors are versatile enough to measure both liquid and solid oils. Nevertheless, ensure the sensor is suitable for the specific application. This is due to the different dielectric constants that solids and liquids have.

Q3. Do capacitive sensors require any form of maintenance after installation?

One of the great things about capacitive sensors is that they require little to no maintenance during their lifetime. The only time they will need maintenance is when recalibration or occasional inspection is required to ensure accuracy.

Q4. What impact does the temperature have on the performance of capacitive oil level sensors?

Extreme oil temperatures can negatively impact the performance of these sensors. They will affect their internal components or change the oil's dielectric constant. Fortunately, there are sensors marketplace designed to handle extreme temperature environments.
